TIP FRP COLOURED PIGMENT PASTE
TIP manufactures Concentrated Pigment pastes for colouring of Fiber reinforced
Plastics(FRP/GRP) based on polyesters, & epoxy resins.
The pastes are easily dispersible in unsaturated polyester & epoxy resins
TIP manufactures a wide range of easily dispersible pigment pastes for FRP
Moulding/Linning/SMC/DMC/Handlay mouldings.
Properties of TIP Pigment Pastes;
1. Easily dispersible in Polyester, Epoxy, Polyurethane Resins.
2. Wide range of colour shades as per the demands of the decorative or industrial
application requirements Viz:
 Ceramic sanitary ware manufacturers
 Amusement park rides, water Slides, Kiddies playground equipments
 Chemical linings of industrial effluents plants,tanks etc
 Interior & Garden Furnitures
 Transluscent colours for Roffing applications
 FRP sleevings for Electrical insulation requirements
 Lamination grades for coatings on wood & other items
 Matchings available as per ISI, DIN,ASTM,BSS shade cards
3. The TIP range of Colour pastes are based upon the dry Inorganic & organic `
carefully selected for the following properties;
 Lightfastness , outdoor durability
 Heat Stability , chemical stability, ease of dispersion
 Excellent Gloss retention over a period of time
 Conductive & non conductive grades for the diverse electrical application
 Storage stability
 Colour strength
 Curing mechanism of the kind of resin & the moulding procedure adopted
4. DIRECTION FOR USE:
 Mixing Method
TIP Colour paste contains a highly dispersed Pigment which can easily be
redispersed in Polyester Gelcoat/Resin with the help of a slow mechanical stirrer
or by hand for small quantities.
For low viscosity resins ,care should be taken during the dispersion of the paste in
the resin so as to avoid any shade variations due to improper mixing.
5. MECHANICAL & CHEMICAL PROPERTIES:
We select the Pigments ,Resins , Additives to obtain the maximum :
 Ease of dispersion & compatibility
 No adverse effect on Gel Time
 Resistance to UV light, chlorine water, Soap ,alkalis, acids, temperatures etc
 As per the specific handling & storage conditions of the moulded product
6. ELECTRICAL INSULATION :
TIP also offers pigments for Non conductive moulding applications .
7.COMPATIBILITY:
TIP offers Pigment pastes suitable for various grades of Polyester resin mouldings Viz:
General Purpose(GP), Isothalic Resins, O-phthalic, Bisphenol grade, FR & also Pigments
suitable for mouldings based on Epoxy & Polyurethane for SMC/DMC/Flooring grade Epoxy
resins . Intermixing of TIP pigments is possible
We also offer Special grades of pigments for Fire Retardant (FR) grade of resins.
8. IN HOUSE LAB-TESTING:
We test the Pigments for the following properties before it is dispatched to the clients:
 Shade/Colour matching
 Ease of dispersion or mixing with the suitable resin or the gelcoat
 Uniformity of colour of the present batch with reference to the previous batch
supplied to the client
 Opacity,Hiding power,Tinting strength
 Transluscency for the pigments meant for tranluscent effects mouldings
Our Pigments are used in India by the flowing industries:
1.Sanitary applications :Bathtubs,Miror frames, Dice stools,Flush doors etc
2.FRP Moulded Furnitures: Light weight sofa sets,Trolleys,Garden tables ,Swings etc
3.Construction industry: Chemical Storage tanks linning,Storage water tanks (Food grade)
FDA Approved pigments,Columns & beams reinforcements, FRP pultruded rebars ,
I- Beams,channels, Off shore drilling platforms with pigments having special
Anticorrosive properties
4. Automobiles: front & rear bumpers, dash Boards, Mirror frames,Car body tops, Auto-
Rikshaws hood etc
5.Industrial applications: Cooling towers, Electrical Bus bar supports,dowels,etc
We are in a position to supply you Pigments with ISI, DIN ,BSS,ASTM standards.
TECHNICAL PARAMETERS:
ITEM: Pigment Paste Concentrate
APPERANCE: Thick highly viscose paste
Solids % NVM 100%
Specific Gravity 1.51 to 2.85
Shelf Life minimum 1 year if stored properly in Closed container away from direct Sunlight
Water Misibility Insoluble
Dosage 2 % to 18 % max on resin**
Applications: Mainly used as colourant in manufacture of mouldings of
FRP,GRP,PMMA,MMA,Epoxy Castings,Floorings etc
** Depending upon the application area & weatherability requirements
